Pfieffer HiCube 80 Eco voltage requirement 90-132 V AC, 50/60 Hz; 185-265 V AC, 50/60 Hz
Mains requirement 110 – 240 V AC, 50/60 Hz
Weight 12.1 kg | 26.68 lb

Powerful and versatile

Turbopump with gauge HiPace 80

Configurable for every application: Customize the HiCube Neo to your individual needs.

What’s so special about the HiCube vacuum solution: The combination of a turbopump with gauge from the HiPace series and a backing pump with gauge designed for the user’s specific application needs. We offer you the HiCube in Pro and Classic versions; available with dry compressing or oil-sealed backing pump with gauge and an ultimate pressure of up to 5 · 10-10 hPa.

MVP 015 Diaphragm pump with gauge

vacuum, the pump with gaugeing station automatically reduces the backing pump with gauge output. This results in maximum energy savings.
The Hicube 80 Station has a modern design with the latest turbo pump with gauge and electronics technology.
Customer benefits

Laboratory applications
pump with gaugeing speed for N2 67 l/s
Pfeiffer HiPace 80 Overview:
Gas analysis
Mains requirement: power consumption 170 W
Type Turbo pump with gaugeing station

Rely on the proven robustness and reliability of the HiCube Neo, designed for demanding conditions. The open design enables easy maintenance and uncomplicated access to the components. In addition, the energy-efficient stand-by mode of the backing pump with gauge ensures lower energy consumption and therefore reduced operating costs.
The HiCube Neo is ready for immediate use thanks to plug-and-play. It is controlled intuitively via the 7″ touch screen display. Benefit from remote control via web server and detailed measurement data recording for optimum process control. Combine the HiCube Neo with our comprehensive portfolio of measuring devices and accessories for customized solutions.

Reliability meets energy efficiency

Flange (out) Silencer, G 1/8″

Pfeiffer HiPace 80 Technical Data:
The complete Solution for High Vacuum Applications

Vacuum furnaces

All HiCube Eco turbo pump with gaugeing stations are fitted with particularly energy-efficient backing pump with gauges that have a DC drive. The turbopump with gauge and the backing pump with gauge form a single unit in the pump with gaugeing station. If there is no gas load in the
NEW Pfeiffer HiCube™ 80 Eco Benchtop Turbomolecular pump with gauge Station CF 4.5 inch Inlet with Cold Cathode Pirani X MPT 200 AR Vacuum Gauge (CF 2.75 inlet) and Cable. Pfeiffer Part Number PM183255-T
The Pfeiffer Vacuum HiCube80 Eco Turbo pump with gaugeing Station is the trully portable and bench top pump with gaugeing unit for many of the High Vacuum Applications. CF-F Inlet Flange makes this system trully Ultra High Vacuum (UHV).
Mains connection: Voltage 100 – 240 V

Discover the HiCube Neo – our latest generation of turbopump with gaugeing systems that combine outstanding performance, flexibility and user-friendliness in an innovative design.
Pfeiffer Vacuum HiCube80 Eco Turbo pump with gaugeing Station, Includes HiPace 80 Turbo pump with gauge (DN 63 ISO-K), MVP 015-2 Diaphragm Vacuum pump with gauge and DCU 002 Control Unit, PMS03555, HiCube80 Eco Turbo Station PM015886-AT

Ultimate pressure < 1 · 10-7 hPa | < 7.5 · 10-8 Torr | < 1 · 10-7 mbar
Especially in combination with the HiPace 300 H turbopump with gauge’s exceptionally high compression, the pump with gaugeing station can now reach high ultimate pressures faster. Until now, with conventional turbopump with gauges, these pressures could only be reached using significantly larger and more energy-intensive backing pump with gauges.
Simple operation with touch display: Intuitive control for effortless operation.
PFEIFFER HICUBE 80 ECO TURBO pump with gaugeING STATION, INCLUDES HIPACE 80 TURBO pump with gauge (DN 63 ISO-K), MVP 015-2 DIAPHRAGM VACUUM pump with gauge AND DCU 002 CONTROL UNIT, PMS03555, PM015886-AT
Pfeiffer HiCube 80 Eco comes with DN 63 ISO-K inlet flange

Desktop and stand-alone versions available: Flexibility for different requirements.
Backing pump with gauge MVP 015-2
Intuitive control and analysis

This is the new enhanced version of the Hi Cube Eco 80:

pump with gaugeing speed backing pump with gauge at 50 Hz 1 m³/h | 0.59 cfm | 16.67 l/min
Features:

Ultimate pressure without gas ballast < 1 · 10-7 hPa | < 7.5 · 10-8 Torr | < 1 · 10-7 mbar
Thanks to their mobility, all HiCube pump with gaugeing stations are the easiest way to generate high vacuum right where it’s needed. Its robust engineering and the ready-to-connect, fully automated
DCU 002 Control Unit
Compact series of pump with gaugeing stations for all high vacuum applications
The HiCube Eco turbo pump with gaugeing station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopump with gauges and backing pump with gauges, the HiCube Eco can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Eco pump with gaugeing stations feature connectivity for digital pressure sensors.
BACKING pump with gaugeS MVP 015-2 • MVP 015-4 • MVP 030-3
Innovative turbopump with gauge units for precise high vacuum applications

Pfeiffer HiPace 80 Features:
pump with gauge down of cryostats
Residual gas analysis

Sound pressure level ≤50 dB(A)
TURBO HiPace 80

Proven robust and reliable: Rely on proven reliability and robustness.
The HiCube Eco turbo pump with gaugeing station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopump with gauges and backing pump with gauges, the HiCube Eco can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Eco pump with gaugeing stations feature connectivity for digital pressure sensors.
The DCU 002 can also be removed from the metal case and used as a remote control. This pump with gaugeing station will pump with gauge down to 10-8 Torr and the XMPT 200 AR Cold Cathode Pirani Gauge will read to 3.75 X 10-9. This unit is completely plug and play and easily integrates well with other Pfeiffer Vacuum Gauges. A power cable is NOT supplied with this unit. For complete instruction manuals on the HiCube 80 Eco pump with gaugeing station and X MPT 200 AR gauge, scroll down to (AVAILABLE DOWNLOADS) below and download the PDF’s.

vacuum, the pump with gaugeing station automatically reduces the backing pump with gauge output. This results in maximum energy savings.

Inlet flange: DN 63 ISO-K

Flange (in) DN 63 ISO-K

This NEW Pfeiffer HiCube 80 Eco is the complete solution for high vacuum applications. It is modular, flexible, compact and versatile. Comes with a HiPace 80 Turbo pump with gauge with fan cooling included and a CF 4.5 inch inlet flange, MVP 015-2 Diaphragm (Backing/Roughing pump with gauge), TPS 110 Power Supply Pack and a DCU 002 (Display and Control Unit) This Pfeiffer HiPace 80 pump with gaugeing station also comes with a XPT 200 AR (Analog Relay) Pressure Gauge with Set Points, and CF 2.75 inch inlet) This Gauge is the “X” PT MPT 200 with analog relay and set points. (not the standard version MPT 200 gauge which has no analog relays or set points). The extra (8-pin, A-coded) connector on the gauge with the text “analog/relay” can be used to connect to an ActiveLine controller and to evaluate the switching contacts. The analog signal and relay contacts can also be evaluated using customer-specific circuitry.
Thanks to the modular design principle, we can offer you never-before-seen versatility with the HiCube series that satisfies the widest range of requirements in the pump with gaugeing speed range from 35 l/s to 685 l/s. Turbopump with gauge and backing pump with gauge are matched perfectly to one another: “Plug and Play” the way you want it.

APPLICATIONS research & development • accelerators • analysis & surface physics • vacuum process technology • general vacuum applications
All HiCube Eco NEO turbo pump with gaugeing stations are fitted with particularly energy-efficient backing pump with gauges that have a DC drive. The turbopump with gauge and the backing pump with gauge form a single unit in the pump with gaugeing station. If there is no gas load in the
Pfeiffer HiCube 80 Eco Turbo pump with gaugeing Station, Includes HiPace 80 Turbo pump with gauge (DN 40 ISO-K), MVP 015-2 Diaphragm Vacuum pump with gauge and DCU 002 Control Unit, PMS03557, HiCube 80 Eco PM 015 888-T Hicube80 Eco
Remote control via web server possible: Convenient monitoring wherever you are.

Areas of application
Pfeiffer Vacuum
Mains requirement: frequency (range) 50/60 Hz

The HiCube Neo redefines performance with an impressive pump with gaugeing speed of 80 – 800 l/s, ideal for demanding high vacuum applications. The HiPace 300 H even enables ultra-high vacuum up to 10-10 hPa. The availability of various backing pump with gauges, such as diaphragm, rotary vane, scroll and multi-stage Roots pump with gauges, makes it extremely versatile. Whether as a compact desktop solution or as a stand-alone unit, the HiCube Neo adapts to any requirement.

Power consumption max. 170 W
Measurement data recording: Precise recording for detailed analysis.

Cooling method, standard Air

pump with gaugeing speed : 67 l/s
The HiCube Neo turbopump with gaugeing unit is the ideal partner for applications in industry and research & development when it comes to generating high vacuum or pump with gaugeing out small volumes. Typical fields of application are
Ultimate pressure: < 1 x 10-7 mbar
Calibration of vacuum gauges
HiCube Neo: The Future of Vacuum Technology
Hi Cube Eco NEO
New Pfeiffer HiCube 80 Eco Turbo pump with gaugeing Station, Includes HiPace 80 Turbo pump with gauge (DN 63 ISO-K), MVP 015-2 Diaphragm Vacuum pump with gauge and DCU 002 Control Unit, PMS03555, PM015886-AT
Technical Specs

What’s so special about the HiCube vacuum solution: The combination of a turbopump with gauge from the HiPace series and a backing pump with gauge designed for the user’s specific application needs. We offer you the HiCube in Pro and Classic versions; available with dry compressing or oil-sealed backing pump with gauge and an ultimate pressure of up to 5 · 10-10 hPa.

Air-cooled and ready for operation with HiPace 80 Turbo pump with gauge and MVP 015 Dry Diaphragm Backing pump with gauge

Additional information

Brand

Pfeiffer

Pfeiffer Vacuum Technology AG is a German manufacturer of vacuum pumps. It is headquartered in Aßlar in Germany with 70% of the total production catering to the export market.

Pfeiffer HiCube 80 Eco – Data Sheet

Pfeiffer HiCube Eco – Operating Instructions

Pfeiffer HiPace 80 – Operating Instructions

Pfeiffer MVP 015-2 DC and 015-4 DC – Operating Instructions

Pfeiffer TC110 – Operating Instructions

Pfeiffer DCU 002 – Operating Instructions

Pfeiffer MPT 200 AR DataSheet

Pfeiffer MPT 200 AR Instruction Manual

Pfeiffer PKR 361 DataSheet

Pfeiffer PKR 361 Instruction Manual
