The HiCube Eco turbo pumping station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopumps and backing pumps, the HiCube Eco can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Eco pumping stations feature connectivity for digital pressure sensors.
Flange (out) Silencer, G 1/8″
The HiCube Eco turbo pumping station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopumps and backing pumps, the HiCube Eco can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Eco pumping stations feature connectivity for digital pressure sensors.
Small coating system
Analysis and surface physics
“Plug and Play” – no installation or cabling required

Plug and play solution with HiPace 30 turbopump and multistage diaphragm pump MVP 015-2
Direct connection of vacuum gauges possible
This NEW Pfeiffer HiCube 30 Eco is the complete solution for high vacuum applications. Modular, flexible, compact, versatile and pumping down to 10-8 Torr. Comes with a HiPace 30 Turbo Pump with fan cooling included and a DN63 CF-F CF 4.5 in inlet flange, MVP 015-2 Diaphragm (Backing/Roughing Pump) TPS 110 Power Supply Pack and a DCU 002 (Display and Control Unit). The DCU can also be removed from the metal case and used as a remote control. This System is completely plug and play and easily integrates well with Pfeiffer Pressure Gauges. For complete documentation on these HiCube Systems look to the left and download the PDF’s.
Sound pressure level ≤ 50 dB(A)

Laboratory applications
Easy integration of pressure gauges from the accessories
Complete, dry, high-vacuum pumping system backed by diaphragm pump
Mains requirement 110 – 240 V AC, 50/60 Hz
Pfeiffer Hicube 30 Eco Turbo Pumping Station, Includes HiPace 30 Turbo Pump DN 63 CF-F, MVP 015-2 Diaphragm Vacuum Pump And DCU 002 Control Unit, PMS7210000
Flange (in) DN 63 CF-F
The combination of a turbopump from the HiPace series and a backing pump designed for the user’s specific application needs. We offer you the HiCube in Pro and Classic versions; available with dry compressing or oil-sealed backing pump and an ultimate pressure of 10-8 Torr

All HiCube Eco turbo pumping stations are fitted with particularly energy-efficient backing pumps that have a DC drive. The turbopump and the backing pump form a single unit in the pumping station. If there is no gas load in the

Customer benefits
Integrated drive electronics; no additional control system needed
The Hicube 30 Eco Station has a modern design with the latest turbo pump and electronics technology.
vacuum, the pumping station automatically reduces the backing pump output. This results in maximum energy savings.
New Pfeiffer Hicube 30 Eco Turbo Pumping Station, Includes HiPace 30 Turbo Pump DN 63 CF-F, MVP 015-2Â Diaphragm Vacuum Pump And DCU 002 Control Unit, PMS7210000, PFEIFFER HICUBE30 ECO Gauge Package
Modular design enables easy access to individual pumping components
Turbopump HiPace 30
vacuum, the pumping station automatically reduces the backing pump output. This results in maximum energy savings.

Tube manufacture
Thanks to the modular design principle, we can offer you never-before-seen versatility with the HiCube series that satisfies the widest range of requirements in the pumping speed range from 35 l/s to 685 l/s. Turbopump and backing pump are matched perfectly to one another: “Plug and Play” the way you want it.
Ultimate pressure < 1 · 10-8 hPa | < 7.5 · 10-9 Torr | < 1 · 10-8 mbar
Pumping speed backing pump at 50 Hz 1 m³/h | 0.59 cfm | 16.67 l/min
Weight 12.9 kg | 28.44 lb
HiCube 30 Eco Turbo Pumping Station W/HiPace 30 Turbo Pump MVP-015-2 Diaphram Pump NEW Specifications
Pfeiffer HiCube 30 Eco Overview:
Vacuum process technology

The Pfeiffer Vacuum HiCube30 Eco Turbo Pumping Station is the trully portable and bench top pumping unit for many of the High Vacuum Applications.

The HiCube Eco turbo pumping station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopumps and backing pumps, the HiCube Eco can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Eco pumping stations feature connectivity for digital pressure sensors.
Compact high performance pumping station for all high and ultrahigh vacuum applications
Type Turbo pumping station
Thermal evaporation and sputtering systems

The Pfeiffer Vacuum HiCube30 Eco Turbo Pumping Station is the truly portable and bench top pumping unit for many of the High Vacuum Applications.

Mains requirement: frequency (range) 50/60 Hz

Categories: Dry High Vacuum Pumps, Dry Turbo, Dry Vacuum, Eco Turbo Pumping Station, New Dry High Vacuum, New Dry Vacuum, New High Vacuum Pumps, New Pfeiffer Alcatel, New Pfeiffer Dry Vacuum, New Pfeiffer Vacuum Pumps, New Vacuum Pumps, New Vacuum Pumps & Ovens, Pfeiffer Adixen Alcatel, Pfeiffer Adixon Alcatel Turbo Pump, Turbo, Turbo Pumped High Vacuum Systems, Vacuum Pumps
Pumping speed for N2 32 l/s
Accelerators

HiCube 30 Eco Key Features & Attributes:

Easy integration of pressure gauges from the accessories
Fore-vacuum safety valve (optional) prevents the recipient from venting in the event of a power failure
Pfeiffer Hicube 30 Eco Technical Data:
Powerful technology

Intermittent mode adapts the pumping station to the process conditions and saves up to 90 % energy

PFEIFFER HICUBE 30 ECO TURBO PUMPING STATION, INCLUDES HIPACE 30 TURBO PUMP DN 63 CF-F, MVP 015-2 DIAPHRAGM VACUUM PUMP AND DCU 002 CONTROL UNIT, PMS7210000

Ultimate pressure of 1 x 10-7 mbar for ISO flanges and 1 x 10-8 for CF versions
Modular design affords simple customization for the application in question
Ultimate pressure without gas ballast < 1 · 10-8 hPa | < 7.5 · 10-9 Torr | < 1 · 10-8 mbar
Maximum energy savings
Backing pump MVP 015-2
Research and development
Pfeiffer HiCube 30 | Turbo pumping station compact high performance pumping station for all high and ultrahigh vacuum applications plug and play solution with HiPace 30 turbopump and multistage diaphragm pump MVP 015-2 Intermittent mode adapts the pumping station to the process conditions and saves up to 90% energy Easy integration of pressure gauges from the accessories
Pfeiffer Vacuum
Compact high performance pumping station for all high and ultrahigh vacuum applications

Plug-and-play design eliminates installation hassles and unnecessary cabling
Leak detection
UL/CSA certification

All HiCube Eco turbo pumping stations are fitted with particularly energy-efficient backing pumps that have a DC drive. The turbopump and the backing pump form a single unit in the pumping station. If there is no gas load in the
Optimally inter-coordinated combination of turbopump and backing pump; for the widest range of applications
Especially in combination with the HiPace 300 H turbopump’s exceptionally high compression, the pumping station can now reach high ultimate pressures faster. Until now, with conventional turbopumps, these pressures could only be reached using significantly larger and more energy-intensive backing pumps.

Service friendly, due to good accessibility of the individual components
Spectroscopy
The complete Solution for High Vacuum Applications
Power consumption max. 170 W
What’s so special about the HiCube vacuum solution: The combination of a turbopump from the HiPace series and a backing pump designed for the user’s specific application needs. We offer you the HiCube in Pro and Classic versions; available with dry compressing or oil-sealed backing pump and an ultimate pressure of up to 5 · 10-10 hPa.
Surface science
Intermittent mode adapts the pumping station to the process conditions and saves up to 90% energy
All HiCube Eco turbo pumping stations are fitted with particularly energy-efficient backing pumps that have a DC drive. The turbopump and the backing pump form a single unit in the pumping station. If there is no gas load in the vacuum, the pumping station automatically reduces the backing pump output. This results in maximum energy savings.
The Hicube 30 Eco Station has a modern design with the latest turbo pump and electronics technology.

Enables operation and connection of gauges

Hi Cube Eco

Pfeiffer offers a low-cost compact turbo drag pumping station ideal for analytical and R&D applications.
Pfeiffer HiCube 30 Eco Overview:
Mains requirement: power consumption 170 W
Thanks to their mobility, all HiCube pumping stations are the easiest way to generate high vacuum right where it’s needed. Its robust engineering and the ready-to-connect, fully automated pump unit assure the utmost in dependability.

Robust engineering makes for long service life and high reliability
General vacuum applications
Adapts ideally to all high and ultra-high vacuum applications due to its modular design
What’s so special about the HiCube vacuum solution: The combination of a turbopump from the HiPace series and a backing pump designed for the user’s specific application needs. We offer you the HiCube in Pro and Classic versions; available with dry compressing or oil-sealed backing pump and an ultimate pressure of up to 5 · 10-10 hPa.
Mains requirement: voltage 100 – 240 V
Connection for pressure gauges

Applications:
Easy data collection and analysis
Plug and play solution with HiPace 30 turbopump and multistage diaphragm pump MVP 030-3
Features:
Integrated turbo pump controller for ease of operation

Cooling method, standard Air

Applications

Integrated air-cooling kit

Additional information

Brand

Pfeiffer

Pfeiffer Vacuum Technology AG is a German manufacturer of vacuum pumps. It is headquartered in Aßlar in Germany with 70% of the total production catering to the export market.
