Krytox™ High-Performance Lubricants Product Guide

Lubricants for the Most Demanding Applications

Made only from fluorine, carbon, and oxygen atoms, Krytox™ perfluoropolyether (PFPE) lubricants are chemically inert, non-toxic, and nonflammable. Krytox™ oils and greases provide superior quality lubrication under extreme conditions, including operating ranges from -73 to 360 °C (-99 to 680 °F). Krytox™ lubricants offer superior value because:

Smaller amounts of lubricant are needed to produce effective results
They require less maintenance
Downtime is reduced significantly
Performance Lubricants Provide the Solution You Need

Various industries have different requirements for the greases and oils they need to keep parts lubricated and equipment running without disruptions. Chemours offers a family series of Krytox™ performance lubricants to meet these specific needs.

The products within the Krytox™ family series include different grades of lubricants that deliver distinct viscosity, performance, temperature and chemical resistance, and temperature ranges. In this way, every application can have a lubricant perfectly matched to the conditions under which its equipment operates.

The Krytox™ lubricants family series include:

Aerospace Greases and Oils
Automotive (AUT) Greases
Gearbox Greases and Oils
General-Purpose Lubricants (GPL)
Low Vapor Pressure (LVP) and Vacuum Pump Fluid (VPF) Lubricants
Non-Reactive (NRT) Greases
Corrugator (CORR) Greases
Extreme High Temperature (XHT) Greases and Oils
Extreme Performance (XP) Greases and Oils
Fluoroguard™ Polymer Additives
Special Application Lubricants

KRYTOX PFPE OILS & GREASES

Krytox™ oils are made from only fluorine, carbon, and oxygen — a mixture of compounds collectively known as perfluoropolyether (PFPE). Krytox™ perfluorinated oils deliver high performance, perform at wide temperature ranges, and provide superior quality lubrication under extreme conditions in comparison to hydrocarbon alternatives.

Krytox™ Product Line Brochure

Krytox™ Product Selector Guide

Krytox™ Use with Reactive Chemicals

Krytox™ greases, using the most advanced lubricant formulated from space-age fluoropolymer technology — are created by thickening synthetic perfluoropolyether (PFPE) base oils with micro-fine polytetrafluoroethylene (PTFE) powder, creating a white, nontoxic grease that provides excellent lubrication in demanding applications. The PTFE thickener forms a barrier that holds the base oil at friction contact points for long-term lubrication without requiring complicated oil recirculation systems.

Krytox™ Applications & Uses by Industry

Krytox™ GPL Delivers Performance.

Oxygen-safe Krytox™ oils and greases combine stability, high-temperature performance, non-flammability, and chemical inertness with outstanding lubrication under a variety of conditions.

GPL 200–207: white buttery greases with all of the same properties as the GPL 100–107 oils that they are made from, but they are in grease form.

GPL 210–217: black greases that contain 5% molybdenum disulfide added as an extreme pressure additive for highly loaded gears and bearings.

GPL 220–227: white anticorrosion greases that contain 2% sodium nitrite. These grades provide rust protection at ambient temperatures, corrosion protection at high temperatures, and anti-wear protection.

KRYTOX™ GPL SERIES – ABOUT

Krytox™ GPL oils and greases are based on perfluoropolyether (PFPE) oils. This series of synthetic fluorinated lubricants are used in extreme conditions, such as continuous high temperatures up to 260 °C (500 °F), and will survive short-term peak temperatures of up to 270 °C (518 °F). Chemically inert and safe for use around most chemicals, these lubricants are nonflammable and are also safe for use in oxygen service. Krytox oils and greases do not damage plastics or elastomers, nor cause corrosion to metals. They are commonly used as lubricants in aerospace, automotive, industrial, and semiconductor applications, as well as in solving many other routine lubrication problems. In addition, they provide exceptionally long lifetimes in sealed-for-life bearings and extend re-lubrication intervals in bearings that require re-lubrication.

Krytox 1506 PFPE Chemical Inert Vacuum Pump Oil, 2.2 lbs (1 Kg ~0.5 liter)

Description

Krytox 1506 PFPE Chemical Inert Vacuum Pump Oil, 2 lbs (1 Kg ~0.5 liter)

Krytox 1506 PFPE, sold here by the 2 lbs (1 Kg ~0.5 liter) containers, is for use in chemical processes which require inert mechanical vacuum pump oil fluids. Krytox oil is specified by Edwards to meet Rotary Vane chemical inert vacuum pump specifications.

Designed for Edwards Rotary Vane Pumps:
Edwards Rotary Vane Models:
RV3, RV5, RV8, RV12, ELab2, Speedivac2, E2M0.7, E2M1, E2M1.5, E2M2, E2M5, E2M8, E1M12, E2M12, E1M18, E2M18, E2M28, E2M30, E1M40, E2M40, E1M80, E2M80, E1M175, E2M175, E1M275, E2M275 Vacuum Pumps.

Chemours Krytox GPL 105 Oil 2.2 lb / 1kg Bottle Perfluoropolyether (PFPE)

When you’re choosing a lubricant for critical applications, there’s no room for doubt. Maximum durability isn’t just desired, it’s required. That’s when you need the most advanced lubricant formulated from space-age fluoropolymer technology.

Krytox GPL Delivers Performance. Oxygen-safe Krytox oils and greases combine stability, high-temperature performance, non-flammability, and chemical inertness with outstanding lubrication under a variety of conditions.

Originally developed for the U.S. Space Program, Krytox Performance Lubricants are a family of fluorinated synthetic oils and PTFE thickened greases that perform where conventional lubricants fail. Krytox Lubricants exhibit superior lubricity, high load carrying ability and extra wear protection. Excellent for high temperature applications and chemically aggressive environments. Available in general purpose, mil-spec grade and food grades. Some lubricants also have a National Stock Number.

Advantages of Chemours Krytox GPL 105 Oil

High Temperature Stability, up to 800°F / 426°C
Wide Operating Range, from -103°F (-75°C) to greater than 800°F (426°C), compared with hydrocarbon lubricants with an operating range of 0°F (-18°C) to 210°F (98°C).
Oxygen Compatibility, safe for oxygen service.
Chemical Inertness. Insoluble in hydrocarbons, petroleum distillates, water, steam, chemical solvents and acids/bases. Provides extra protection against aggressive chemicals that degrade conventional lubricants.
Ionizing Radiation Resistance, more stable than most hydrocarbon and synthetic materials.
Compatible with plastics, elastomers, metals and ceramics.
Extends Service Life of critical components. Reduces down time and maintenance costs.
Low Vapor Pressure
Low Outgassing
Nonflammable
Nontoxic
No Migration, contains no silicones.
Food Grades (H1 & H2)
Aerospace Grades
Mil-spec Grades
