CF Rotatable Blanks with Thru Holes

CF Rotatable Blanks with Thru Holes are made from 304 Stainless Steel and feature a rotatable flange and though-holes for easy of assembly. These can be baked to 450 Celsius and utilize a copper gasket for reliable ultra-high vacuum service.

These are also offered in Metric and Standard threads.

UPC: SKU: N/A Categories: , , , Tags: , , , , , , , , , , , , , ,
Brand:High Vac Depot
Original price was: $17.55.Current price is: $17.20.
SKU: CF-BL-133R
Original price was: $22.10.Current price is: $21.66.
SKU: CF-BL-212R
Original price was: $27.30.Current price is: $26.75.
SKU: CF-BL-275R
Original price was: $53.30.Current price is: $52.23.
SKU: CF-BL-338R
Original price was: $88.40.Current price is: $86.63.
SKU: CF-BL-450R
Original price was: $110.50.Current price is: $108.29.
SKU: CF-BL-462R
Original price was: $118.30.Current price is: $115.93.
SKU: CF-BL-600R
Original price was: $130.00.Current price is: $127.40.
SKU: CF-BL-675R
Original price was: $195.00.Current price is: $191.10.
SKU: CF-BL-800R
Original price was: $598.00.Current price is: $586.04.
SKU: CF-BL-1000R
Original price was: $1,183.00.Current price is: $1,159.34.
SKU: CF-BL-1200R
Original price was: $1,267.50.Current price is: $1,242.15.
SKU: CF-BL-1325R
Original price was: $1,625.00.Current price is: $1,592.50.
SKU: CF-BL-1400R
Original price was: $2,587.00.Current price is: $2,535.26.
SKU: CF-BL-1650R
View cart

Description

Conflat Rotatable Blanks with Thru Holes

Conflat Rotatable Blanks with Thru Holes are made from 304 Stainless Steel and feature a rotatable flange and though-holes for easy of assembly. These can be baked to 450 Celsius and utilize a copper gasket for reliable ultra-high vacuum service.

These are also offered in Metric and Inch threads.

Additional information

Weight N/A
CF Blank Rotatable - Thru

, , , , , , , , , , , , ,

Brand

High Vac Depot

High Vac Depot provides practical vacuum solutions for your industrial or research process. Our goal is to provide a large selection of well-known vacuum products that suit your technical needs and budget.

Catalog Part #

 Type Flange A B D PCD Quantity of Bolt Bolt Hole
in in in in Holes Diameter in[mm]
[mm] [mm] [mm] [mm] or
Thread
CF-BL-133R Thru Holes CF1.33″/CF16 1.33 0.76 0.3 1.06 6 0.17
[33.70] [19.41] [7.60] [26.97] [4.37]
CF-BL-212R Thru Holes CF2.12″/CF25 2.12 1.1 0.47 1.63 4 0.26
[53.80] [27.94] [11.90] [41.28] [6.73]
CF-BL-275R Thru Holes CF2.75″/CF35 2.73 1.9 0.5 2.31 6 0.26
[69.30] [48.31] [12.70] [58.72] [6.73]
CF-BL-338R Thru Holes CF3.38″/CF50 3.36 2.15 0.69 2.85 8 0.33
[85.30] [54.50] [17.40] [72.39] [8.43]
CF-BL-450R Thru Holes CF4.50″/CF63 4.47 2.85 0.75 3.63 8 0.33
[113.50] [72.39] [19.10] [92.15] [8.43]
CF-BL-462R Thru Holes CF4.62″/CF80 4.61 3.14 0.81 4.03 10 0.33
[117.00] [79.71] [20.60] [102.36] [8.43]
CF-BL-600R Thru Holes CF6.00″/CF100 5.97 4.18 0.84 5.13 16 0.33
[151.60] [106.17] [21.30] [130.25] [8.43]
CF-BL-675R Thru Holes CF6.75″/CF130 6.72 5.1 0.84 5.97 18 0.33
[170.69] [129.50] [21.30] [151.61] [8.43]
CF-BL-800R Thru Holes CF8.00″/CF160 7.97 6.13 0.94 7.13 20 0.33
[202.44] [155.70] [23.90] [181.05] [8.43]
CF-BL-1000R Thru Holes CF10.00″/CF200 9.97 8.2 0.97 9.13 24 0.33
[253.24] [208.28] [24.60] [231.85] [8.43]
CF-BL-1200R Thru Holes CF12.00″/CF250 11.97 10.08 1.02 11.18 32 0.33
[304.04] [256.03] [25.90] [283.97] [8.43]
CF-BL-1325R Thru Holes CF13.25″/CF270 13.22 10.88 1.12 12.06 30 0.41
[335.79] [276.30] [28.45] [306.32] [10.49]
CF-BL-1400R Thru Holes CF14.00″/CF300 13.97 12.04 1.12 12.81 30 0.41
[354.84] [305.82] [28.45] [325.37] [10.49]
CF-BL-1650R Thru Holes CF16.50″/CF350 16.47 14.16 1.12 15.31 36 0.41
[418.34] [359.61] [28.45] [388.87] [10.49]
